ControlWave Base Unit (Continued)
DESCRIPTION PART NO.
Local Termination I/O Modules
16 AI 4-20 mA Internally or Externally powered AI 396352-01-4
16 AI 1-5 V & ext. powered 4-20 (with 250 ohm on input) 396352-02-2
8 AI 4-20 mA Internally or Externally powered AI 396352-03-0
8 AI 1-5 V & ext. powered 4-20 (with 250 ohm on input) 396352-04-9
6 TC B, R, S, J, E, K, T, C, N, + 10 mV 396877-01-0
4 RTD 2, 3, or 4 wire platinum RTD 396878-01-6
8 AO 4-20 mA 396353-01-0
8 AO 1-5 V 396353-02-9
4 AO 4-20 mA 396353-03-7
32 DI Selectable Internally or Externally powered Dry Contact 396357-01-6
16 DI Selectable Internally or Externally powered Dry Contact 396357-02-4
32 DO Open Drain - 500 mA current capability, 30 mS lter 396358-01-2
16 DO Open Drain - 500 mA current capability, 30 mS lter 396358-02-0
12 UDI (HighSpeed
Counter) Both 12 and 6 UDI High speed counters come with selectable 396362-01-0
6 UDI (HighSpeed Counter) debounce (enabled/disable) @ (0-10 KHz) Low or High speed 396362-02-8
Notes
Note 1: CE approval requires the CE Accessories kits.
Note 2: RS485 Comm port 3 is RJ45. RS 485 ports have 500 V isolation
Note 3: The I/O Expansion Rack CPU interfaces to the main ControlWave Chassis CPU via Ethernet
Note 4: For conformal coating add -C sufx to each part number.
