Installing Optional Network Expansion Module (NEM)
Matrix DFE-Gold Series PoE Module 4H4285-49 Installation Guide 3-3
Installing Optional Network Expansion Module (NEM)
APhillipsscrewdriverisrequiredtoinstallanoptionalnetworkexpan sionmoduleinto
the4H4285‐49.
RefertoyourreleasenotesortheEnterasys Networkswebsiteforthelatestavailable
networkexpansionmodules.
Installingannetworkexpansionmoduleinvolves
•removingthesafetycover,
•removingthecoverplatefromthe4H4285‐49,
• attachingthe
NEM,and
•replacingthesafetycover.
SpecificinstallationinstructionsareshippedwitheachNEM.
DFE Module Placement and Installation Rules
TheDFE modulecanbeinstalledinaMatrix E7(refertoFigure 3‐1onpage 3‐4for
placementrules),Matrix N3,Matrix N5,orMatrix N7 chassis.
TheMatrix N3,Matrix N5,orMatrix N7 chassissupportonlyDFEmodulesandthereare
noparticularrulesforinstallingmodules.
Note: Install any optional equipment before proceeding to “DFE Module Placement and
Installation Rules” on page 3-3 for an explanation of the rules to install different series
modules in a Matrix E7 chassis.
Caution: Regardless of which chassis is used, the chassis system must be dedicated to
DFE-Gold modules (4xxxxx) only. Do not insert 7xxxxx modules or other legacy modules
into the same chassis with 4xxxxx modules as this will render the chassis inoperable.
Precaución: Cualquiera que sea el chasis que utilice, recuerde que el sistema debe
aplicarse exclusivamente a los módulos DFE (Distributed Forwarding Engine) de la serie
Gold (4xxxxx). No inserte módulos 7xxxxx ni otros módulos legado dentro de un chasis
con módulos 4xxxxx. Si lo hace, el chasis no funcionará.
