16 • CRT Monitor Mounting Solutions Orderguide • rev.05/13/04 870-03-018
60-156
Wall Track
60-151-099,
Bracket for
Arm to Wall
Track
60-151-099
60-188-099
Suspension Arm
Mounting Systems
The Wall Track mounting system is a flexible, low-cost mounting method that occupies zero floor space.
This system attaches to most vertical surfaces – such as walls, pillars, and machines – and provides
one standard interface that will mount multiple Ergotron components anywhere along its length.
Choose a length of Wall Track that will accommodate the size and number of components you
wish to mount.
Part Description Dimensions
Number H x W
31-016-182 10" Wall Track 10" x 5"
(254 x 127 mm)
31-017-182 26" Wall Track 26" x 5"
(660 x 127 mm)
31-018-182 34" Wall Track 34" x 5"
(864 x 127 mm)
31-019-182 50" Wall Track 50" x 5"
(1270 x 127 mm)
Wall Track Mounting Kits Application…
90-010 Wall Track Mounting Kit (10) Phillips Sheet metal or
self-tapping 14 x 1.5 LG screw wood studs
90-011 Wall Track Mounting Kit (10) Phillips Hollow walls
1/4"-20 x 1.5 LG screw/toggle anchor
Track Mount Bracket Kits Mounting Screws
60-151-099 Bracket for Suspension, Lift, (4) 3/8"-16 x .75"
Fixed Arm to Wall Track hex head screws
60-188-099 Bracket for Extender Arm (4) 3/8"-16 x .75"
to Wall Track hex head screws
60-156 Bracket for Peripheral (4) 3/8"-16 x .63"
to Wall Track button head screws
Note: See the selection of available peripherals on pages 19–21.
Wall Tracks
Caution: Surface construction varies and the
ultimate mounting method you use to attach an
Ergotron mounting system is out of Ergotron’s
control. It is important to consult with the
appropriate local engineering, architectural, or
construction personnel to ensure that an Ergotron
mounting system is mounted properly to handle
applied loads.
Wall Track
configuration
example
Monitor Caddy
Suspension Arm
Keyboard Holder
and Tray
CPU Cabinet
