18 • CRT Monitor Mounting Solutions Orderguide • rev.05/13/04 870-03-018
85-033-000
Wrist Rest
85-025-079
Mouse Pad
99-033-078
Mouse Pouch
77-076-000
77-049-000
77-050-000
85-014-000
Articulating Keyboard Arm, Keyboard Tray w/
Sliding Mouse Tray, and Wrist Rest
Note: See page 25 for information regarding other
keyboard mounts.
75-054-009
75-055-009
75-052-009
75-053-009
Keyboard Solutions
Wire Keyboard Holders: Store your keyboard out of the way, then pull it out when needed.Tilt up or
down in 15˚ increments. Keyboard Holders mount under Caddies and Platforms.
Part Description Dimensions Weight
Number W x D x H Capacity
75-052-009 Wire Keyboard Holder 12-7/8" x 23-1/2" x 4-1/2" 15 lbs
2" drop, pull-out (327 x 597 x 114 mm) (6.8 kg)
75-053-009 Wire Keyboard Holder 12-7/8" x 23-1/2" x 6-1/2" 15 lbs
4" drop, pull-out (327 x 597 x 165 mm) (6.8 kg)
75-064-009 Wire Keyboard Holder 12-7/8" x 23-1/2" x 4-1/2" 15 lbs
2" drop, pull-out (327 x 597 x 114 mm) (6.8 kg)
(10" Lift Arm only)
75-065-009 Wire Keyboard Holder 12-7/8" x 23-1/2" x 6-1/2" 15 lbs
4" drop, pull-out (327 x 597 x 165 mm) (6.8 kg)
(10" Lift Arm only)
Adjustable Keyboard Tray Holders: Store your keyboard out of the way, then pull it out when needed.
Tilt up or down in 15˚ increments. Keyboard Holders mount under Caddies and Platforms. Use with
separately ordered Keyboard/Mouse Trays (see below).
75-054-009 Adj. Keyboard Tray Holder 12-7/8" x 18-3/8" x 4" 15 lbs
2.5" drop, pull-out (327 x 467 x 102 mm) (6.8 kg)
75-055-009 Adj. Keyboard Tray Holder 12-7/8" x 18-3/8" x 7-1/2" 15 lbs
5" drop, pull-out (327 x 467 x 191 mm) (6.8 kg)
Keyboard/Mouse Trays Accessories: Use with the Adjustable Keyboard Tray Holders (see above).
Use with…
77-001-000 Steel Keyboard/Mouse Tray 26" x 8-1/4" 75-052, 75-053
(660 x 210 mm) 75-064 or 75-065
77-049-000 Keyboard Tray 16-1/2" x 7-1/4" x 2" 75-054-009 or
(419 x 184 x 51 mm) 75-055-009
77-050-000 Keyboard Tray w/ Sliding 17-1/2" x 9 to 12" x 2-1/2" 75-054-009 or
Mouse Tray & Wrist Rest (445 x 229 to 305 x 64 mm) 75-055-009
Holder
77-076-000 Keyboard Tray w/ Handle 17-1/2" x 12-1/2" x 3-3/8" 75-054-009 or
and Sliding Mouse Tray (445 x 318 x 86 mm) 75-055-009
85-014-000 Front Mouse Tray 7-1/4" x 7-1/8" x 1" 77-049-000
(184 x 181 x 25 mm)
85-024-000* Sliding Mouse Tray and 77-049-000
Wrist Rest Holder
85-033 Wrist Rest, black 19" x 3" (483 x 76 mm)
85-010-087 Wrist Rest, grey, 19" x 3"
premium, easy-clean (483 x 76 mm)
85-025-079 Mouse Pad 7" x 7" (178 x 178 mm)
99-033-078 Mouse Pouch, grey
* 85-024-000 converts 77-049-000 into 77-050-000.
Articulating Keyboard Arms & Tray: Mount this arm under almost any worksurface or desktop.
Features wide-ranging adjustment: slide forward and back, move up and down 6 inches, rotate 360°,
tilt tray to fore and aft.Very smooth motion and durable construction. Color is black.
75-038 Articulating Keyboard Arm L = 16-7/8" (427 mm) – stored position
77-026-098 Keyboard Tray with Sliding 21" x 10-1/2" x 1-1/2"
Mouse Tray (533 x 267 x 38 mm)
85-008-098 Wrist Rest for 19-1/2" x 2"
Articulating Arm (495 x 51 mm)
85-016-087 Wrist Rest for Art. Arm, 19-1/2" x 2"
grey, premium, easy-clean (495 x 51 mm)
Keyboard Holders,
Trays & Arms
85-024-000
