HSA 822 Hideaway
®
Enclosure • Installation
HSA 822 Hideaway
®
Enclosure • Installation
Installation, cont’d
2-6
6. Remove the plastic strips that protect the flanged edges of
the top of the surface enclosure. If a sticky residue
remains, remove it with an appropriate metal cleaning
product.
CAUTION
Do not use isopropyl alcohol or other solvents to
clean the HSA. Strong solvents will ruin some
finishes.
7. Carefully lower the HSA enclosure into the hole to test the
fit. If necessary, remove the enclosure and use a file or
rasp to enlarge or smooth the edges of the opening.
8. From the underside of the table, bolt the clamshell to the
enclosure with two bolts of optimum length (included)
(figure 2-3).
9. Peel any remaining protective coating from the enclosure.
Mounting
Surface
Full Thread
Mounting Bolts
AAP Cables
Flat Washer
Power Cord
RJ-45 Connectors
Clamshell
HSA 822
C
O
M
P
U
T
E
R
I
N
P
U
T
S
E
L
E
C
T
A
U
D
I
O
Figure 2-3 — Mounting the HSA 822 enclosure
2-7
