HSA 822 Hideaway
®
Enclosure • Introduction
Introduction, cont’d
HSA 822 Hideaway
®
Enclosure
2
Chapter Two
Installation
Installation Overview
Preparing the Routing Template
Preparing the Table and Mounting the Enclosure
Cabling and Installing the AAPs
Cabling the Enclosure
Routing the AAP Cables
Bezels
1-4
The HSA 822 is available in a variety of surface finishes,
including black anodized aluminum, brushed aluminum,
brushed brass, and polished aluminum.
Features
• UL/CUL listing
• CSA certification
• Easy access to connectors and controls
• Durable mechanical movement and latching mechanism
• A variety of surface finishes available
• A variety of colors of included RJ-45 connector bezels
included: black, red, blue, orange, gray, white, ivory,
yellow, and green
The space behind the AAP panel is limited. The online
Connectivity Configurator, available at
www.extron.com, offers guidance as to the fit of AAPs
into this space.
• Compact size
• Easy installation of up to four powered or passive double
space Extron AAPs
• RJ-45 (CAT 5/6) network and data connections
(teminated in accordance with the TIA/EIA 568 A
standard)
• Grounded AC plugs
