Chapter : Using Your FPD 1540 Monitor
www.gateway.com
OSD menus
You can access any of these menus in the OSD:
OSD Menu Option Description
BRIGHTNESS. Adjust the brightness of the
screen. Use the lowest brightness setting you
are comfortable with to maximize the life of the
monitor backlights.
You may need to readjust brightness after the
monitor has warmed up.
CONTRAST. Adjusts the contrast of the
screen.
AUTO CONTRAST. Automatically adjusts the
contrast to the ideal setting for the current
screen resolution.
AUTO ADJUST. Automatically adjusts the
display image position, clock, and phase.
LEFT/RIGHT. Moves the display image left and
right.
DOWN/UP. Moves the display image up and
down.
H. SIZE. Adjusts the size of the display image.
FINE. Adjusts the amount of detail
enhancement.
USER. Adjusts the color temperature.
Choose from the following:
9300 is bluish white.
7500 is greenish white.
6500 is reddish white.
USER lets you customize the Red, Green, and
Blue color levels separately.
AUTO
USER
RGB
48.2 KHz / 59.8 Hz
1024 X 768
EXIT
AUTO
USER
