Modem jack Plug a modem cable into this jack.
Ethernet jack Plug a 10/100 Ethernet network cable into this jack.
Power connector Plug the AC adapter cable into this connector.
Important: If your port replicator has a power
connector on the left side (see “Left” on page 77),
plug the Gateway 405 AC adapter into that
connector. If your port replicator does not have a
power connector on the left side, plug the Gateway
405 AC adapter into this connector.
S/PDIF digital audio
jack
Plug an optical (Toslink) AC-3 digital audio cable into
this jack.
Headphone jack Plug amplified speakers or headphones into this jack.
The built-in speakers on the notebook are turned off
when speakers or headphones are plugged into this
jack.
This jack is turned off when headphones are plugged
into the notebook’s headphone jack.
Line in jack Connect an external audio input source (such as a
stereo) to this jack so you can record sound on your
notebook or play sound through the notebook
speakers.
Component Icon Description
