Using FPC 1000 with a Notebook PC
2.2.2.3 Monitoring Signal Strength and Quality
Signal strength shows the power level of the signal you are receiving. When the signal is
strongest, four bars are shown. When it is weakest, one bar is shown. When the modem is
searching for a signal, the bars will scan from left to right.
Signal Quality measures the actual quality of the signal (signal in relation to surrounding
noise/interference, etc.).
Signal Strength
Signal Quality
Figure 14: Signal Strength and Quality Indicators
2004 Flarion Version 1.0
Flarion Proprietary and Confidential Page 21
