Using FPC 1000 with a Notebook PC
2.2.4. Removing the Antenna from the FPC 1000
When transporting the FPC 1000, it may be helpful remove the antenna.
WARNING
WHEN REMOVING THE ANTENNA FROM THE PC
CARD, DO NOT PULL FROM THE TOP OF THE
ANTENNA. THIS MAY CAUSE THE ANTENNA TO
BREAK.
To remove the antenna from the FPC 1000:
Figure 26: Antenna Aligned with the FPC 1000
2. Grasp the antenna by the molded antenna grips.
Figure 27: Antenna Grips
3. Pull the antenna out of the FPC 1000.
1. Rotate the antenna so that it aligns with the FPC 1000.
FPC 1000
Antenna
(Aligned to FPC 1000)
Antenna Grip
Antenna Grip
2004 Flarion Version 1.0
Flarion Proprietary and Confidential Page 35
