- 6 -GA-7VKML Series Motherboard
English
On-Board Peripherals — 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes.
— 1 Parallel port supports Normal/EPP/ECP mode
— 2 Serial port (COM A, Internal COM B)
— 1 VGA port
— 4 USB ports (Rear USB x 2, Front USB x 2)
— 1 IrDA connector for IR
Hardware Monitor — CPU/System Fan Revolution detect
— CPU/System temperature detect
— System Voltage Detect
On-Board Sound
#
— Realtek ALC101 CODEC
— Line In/Line Out/Mic In/CD_In/AUX_In /Game Port
On-Board Sound ** — Realtek ALC650 CODEC
— Line Out / 2 front speaker
— Line In / 2 rear speaker(by s/w switch)
— Mic In / center& subwoofer(by s/w switch)
— SPDIF out
— CD_In/ AUX_IN/Game Port
On-Board LAN *** — Build in RTL8100 Chipset
PS/2 Connector — PS/2 Keyboard interface and PS/2 Mouse interace
BIOS — Licensed AMI BIOS, 2M bit Flash ROM
— Support Q-Flash Utility
Additional Features — STR(Suspend-To-RAM)
— AC Recovery
— USB KB/Mouse wake up from S3
— PS2 KB/Mouse wake up from S1, S3, S4, S5
— Supports @BIOS
TM
— Supports Easy Tune
TM
4
M Please set the CPU host frequency in accordance with your processor’s specifications.
We don’t recommend you to set the system bus frequency over the CPU’s specification
because these specific bus frequencies are not the standard specifications for C PU,
chipset and most of the peripherals. Whether your system can run under these specific
bus frequencies properly will depend on your hardware configurations, including CPU,
Chipsets,SDRAM,Cards… .etc.
" # " Supported 7VKML PCB VER: 3.2 / 3.3 / 3.4.
" ** " Supported GA-7VKML-P / GA-7VKML-DL (PCB VER:3.4)
" *** " Supported 7VKML (PCB VER: 3.2 ~ 3.4 and 7VKML-P)
