C-24
Fast, Wide Differential SCSI IDs
Before assigning a SCSI device ID to your drive, you need to check
your SCSI device IDs. To check which SCSI device IDs are available
and assign an ID to your device, follow these instructions which use
Table C–10:
1. Write in the type of internal drives currently connected to your
system under the heading “Fast, Wide Differential SCSI Device
Drives” and each drive’s SCSI device ID under the heading “De-
vice ID Number.”
2. Add your new drive to the table.
3. Check to see what SCSI device IDs are not used. You may use
ID numbers 0 through 6 and 8 through 15 if they are not already
in use. If the default ID on your drive does not conflict with any
existing drive IDs, use that ID. If your default address conflicts
with an existing drive ID, assign a new fast, wide differential
SCSI device ID to your drive. Refer to the drive’s installation
documentation for information on changing the device ID.
CAUTION: Do not use SCSI device ID 7 for any device.
Table C–10. Fast, Wide Differential SCSI Device IDs
Device ID (Address) Number
(ID 7 not available)
1st Internal Device
2nd Internal Device
NOTICE: You can have no more than 15 SCSI devices connected to a FWD SCSI bus.
Fast, Wide Differential SCSI Device Drives
6
5
