Top Products
Interfaces
InterfacesInterfaces
Interfaces
Ultra-Slim Desktop
Ultra-Slim DesktopUltra-Slim Desktop
Ultra-Slim Desktop
Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor
Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Serial Port
1 optional
1 standard, 2nd via option 1 standard, 2nd via option
Parallel Port
1 optional
1 1
PS/2
1 Keyboard and 1 Mouse
USB (2.0)
8 ports (6 rear/2 front)
RJ-45 10/100/1000 Network
X
Keyboard
X (PS/2)
Mouse
X (PS/2)
Multibay
1 standard
optional optional
Video (VGA)
X
Audio
X
Power Supply
Power SupplyPower Supply
Power Supply
Ultra-Slim Desktop
Ultra-Slim DesktopUltra-Slim Desktop
Ultra-Slim Desktop
Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor
Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Power Supply
200 watt custom power supply -
Active PFC)
240 watt custom power supply -
Active PFC)
340 watt custom power supply -
Active PFC)
Operating Voltage Range
90 - 132/180 - 264 VAC 90 - 132/180 - 264 VAC 90 - 132/180 - 264 VAC
Rated Voltage Range
100 - 127/200-240 VAC 100 - 127/200-240 VAC 100 - 127/200-240 VAC
Rated Line Frequency
50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range
47 - 63 Hz 47 - 63 Hz 47 - 63 Hz
Rated Input Current
5A/2.5A 5A/2.5A
6A/3A
Heat Dissipation
Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1050 btu/hr
(265 kg-cal/hr)
Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1260 btu/hr
(318 kg-cal/hr
Typical 340 btu/hr
(86 kg-cal/hr)
Maximum 1575 btu/hr
(397 kg-cal/hr)
Power Supply Fan
70mm variable speed 80mm variable speed 92mm variable speed
Energy Star Compliant
X X X
Blue Angel Compliant (<5w in
S5-- Power Off)
X X X
FEMP Standby Power Compliant
(<2W in S5 - Power Off)
X X X
Power Consumption in ES Mode
- Suspend to RAM (S3) (Instantly
Available PC)
2.5W to 3W 2.5W to 3W 2.5W to 3W
Processor/Cache Memory Power
-Down (S3)
< 3W < 3W < 3W
Environmental and Mechanical
Engineering Support Center
(EMESC) - Intranet Web Site only
http://env-webserver.ccm.cpqcorp.net/EMESC/default.htm
QuickSpecs
HP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 SeriesHP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 Series
Technical Specifications
DA - 11948 North America — Version 33 — January 31, 2006
Page 20
