Ultra-slim Desktop
Ultra-slim DesktopUltra-slim Desktop
Ultra-slim Desktop
Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor
Convertible Minitower
Convertible MinitowerConvertible Minitower
Convertible Minitower
Operating System
Microsoft Windows XP
Professional SP1a
X
Microsoft Windows XP
Home SP1a
X
Processor
Intel Pentium 4 processor
CPU Bus Speed Supported
800-MHz
Standard L2 Cache
1024-KB
Chipset
Intel 915 series Express
Intel 915G Express Intel 915G Express
Memory Expansion Slots
3 DIMM's 4 DIMM's 4 DIMM's
Memory Type Supported
Non-ECC DDR Synch Dram (ECC not supported by Chipset)
Memory Speed Supported
DDR Synch DRAM PC3200 (400MHz) non-ECC
Maximum Memory*
3-GB 4-GB 4-GB
Network controller
Integrated Broadcom NetXtreme Gigabit thernet for HP
Graphics
Integrated Intel Graphics Media Accelerator 900
Audio
Integrated digital audio with S/Pdif 6-channel pass-through, stereo microphone, active noise
cancellation and Yamaha XG Lite Softsynth support
*
NOTE:
NOTE: NOTE:
NOTE:
Above 3-GB, all memory may not be available due to system resource requirements.
Expandability
ExpandabilityExpandability
Expandability
PCI slots
1 full-height (4.2"), length (6.6")
2 low-profile (2.5"), length (6.6")
standard;
2 full-height (4.2"), length
(6.875") via optional riser card.
2 full-height (4.2"), length
(13.4") standard;
(2 additional slots available via
optional extender card)
PCI Express x16 slot
--
1 low-profile (2.5"), length (6.6")
1 full-height (4.2"),
length (10.5")
PCI Express x1 slot
--
1 low profile (2.5"), length (6.6")
1 full-height (4.2"),
length (13.4")
AGP slot
none none none
External Bays
1 MultiBay
2 bays (1 - 5.25", length
(8.189"), and 1 - 3.5" (supports
2nd HDD))
4 bays (2 - 5.25", length
(8.189"), 1 - 5.25" length
(5.71") and 1 - 3.5")
Internal Bays
1 - 3.5" hard drive bay 1 - 3.5" hard drive bay
2 - 3.5" hard drive bays
MultiBay
standard
optional via MultiBay adapter optional via MultiBay adapter
IDE
1 IDE connector for opticals 1 IDE connector for opticals 1 IDE connector for opticals
Serial-ATA
1 serial-ATA connector for SATA
hard drive
2 serial-ATA connectors for
SATA hard drives
4 serial-ATA connectors for
SATA hard drives
QuickSpecs
HP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 SeriesHP Compaq Business Desktop dc7100 Series
HP Compaq Business Desktop dc7100 Series
Standard Features
DA - 11948 North America — Version 33 — January 31, 2006
