Bluetooth module
NOTE: This section applies only to computer models equipped with an Intel processor.
NOTE: The Bluetooth module spare part kit does not include the Bluetooth module cable. The
Bluetooth module cable is available using spare part number 647271-001.
Description Spare part number
EDR v.4.0 655792-001
EDR v.3.0 537921-001
Before removing the Bluetooth module and cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 52), and then remove the following components:
●
Optical drive (see
Optical drive on page 53)
●
Hard drive (see
Hard drive on page 56)
●
Keyboard (see
Keyboard on page 65)
●
Top cover (see
Top cover on page 68)
Remove the Bluetooth module and cable:
1.
Disconnect the Bluetooth module cable (1) from the system board.
2.
Release the Bluetooth module cable (2) from the clips built into the speaker and base enclosure.
80 Chapter 4 Removal and replacement procedures
