Changing Display Settings
19
Filename: fx75UGrw.doc Title: Book Title
Template: HP-Print.dot Author: WASSER, Inc. Last Saved By: WASSER, Inc.
Revision #: 30 Page: 19 of 43 Printed: 10/16/00 03:31 PM
The following table briefly describes each of the
options in the OSD main window.
Option Description
Auto
Setup
Automatically adjusts the video level,
image position, and other display settings.
See “Using Auto Setup” on page 21.
Note:
For optimal performance, Auto
Setup may be used whenever you apply a
new mode.
Brightness
Controls the brightness of the display by
adjusting the light output of the backlight.
The default setting of brightness is at
maximum.
Contrast
Adjusts the level of difference between
light and dark areas of the image. Before
using this option, though, you should run
Auto Setup which will automatically adjust
the contrast for you. If you are not satisfied
with the results, you can use the Contrast
option to adjust the contrast yourself.
Note:
Immediately after choosing this
option, the auto level routine may run in
the background for several seconds. Do
not be alarmed by the flashing on your
screen while the display sets the levels.
Option Description
Image Adjust
Opens the Image Adjust window where
you can choose to adjust image
attributes, such as position, scaling,
sharpness, color, and advanced settings.
See “Adjusting the Image” on page 22.
Language Selects the language for the OSD
windows.
OSD Settings Adjusts the vertical and horizontal
position, size, transparency, and timeout
settings of the OSD window.
Restore
Factory
Presets
Returns all OSD settings to the original
factory defaults for the current mode.
Information
Displays the microcode version, the
product name, and the model number of
your display.
Exit
Closes the OSD main window and saves
any changes you have made.
