5) Position the remote temperature sensor in the desired location,
ensuring that the atomic clock can receive the signal.
Note: Mounting with adhesive tape is not recommended as a permanent
mounting solution. Only use the adhesive tape during set-up process.
TROUBLESHOOTING
Problem: The LCD is faint.
Solution: 1) Replace the batteries.
Problem: No reception of WWVB signal
Solution: 1) It may help reception to face the front of the atomic clock in the general
direction of Ft. Collins, Colorado.
2) Wait overnight for signal.
3) Be sure the atomic clock is at least 6 feet (2 meters) from any electrical
devices, i.e. TV sets, computers, or other radio controlled clocks.
4) Remove batteries for five minutes, reinsert and leave the unit alone
overnight without pressing any keys.
Problem: Hour is incorrect (minute and date are correct).
Solution: 1) Be sure the correct time zone and daylight saving time are selected.
Problem: "OF.L“ appears in the indoor temperature section of the LCD
Solution: 1) Move the atomic clock to an area with warmer or cooler surrounding
temperature. Current surrounding temperatures are outside measuring
range.
Problem: "--.-" appears in the outdoor temperature section of the LCD.
Solution: 1) Remove the batteries of both units for one minute, then reinsert them
again. Make sure the batteries are new and fresh.
2) Move the atomic clock closer to the sensor or place the sensor closer to
the atomic clock. Make sure the clock is at a receivable range from the
sensor.
3) Move the units to another location. Interferences from other electrical
devices operating on the same signal frequency (915MHz) may prevent
correct signal transmission and reception.
Problem: "OF.L“ appears in the outdoor temperature section of the LCD.
Solution: 1) Wait until the current surrounding temperature cools down or increases.
Current temperature is outside of the measuring range of the sensor. The
14
outdoor temperature will be displayed again once the current surrounding
temperature is within the range of the sensor.
MAINTENANCE AND CARE INSTRUCTIONS
• Extreme temperatures, vibration, and shock should be avoided to prevent damage to the
units.
• Clean displays and units with a soft, damp cloth. Do not use solvents or scouring agents;
they may mark the displays and casings.
• Do not submerge in water.
• Immediately remove all low powered batteries to avoid leakage and damage.
• Opening the casings invalidates the warranty. Do not try to repair the unit. Contact La
Crosse Technology for repairs.
• Do not make any repairs to the units. Please return it to the original point of purchase.
Opening and tampering with the units may invalidate the warranty.
SPECIFICATIONS:
Temperature measuring range
Indoor : 14.1ºF to 103.8ºF with 0.2ºF resolution
-9.9ºC to +39.9ºC with 0.1ºC resolution
("OF.L" displayed if outside this range)
Outdoor : -39.9ºF to +139.8ºF with 0.2ºF resolution
-39.8ºC to +59.9ºC with 0.1ºC resolution
("OF.L“ displayed if outside this range)
Temperature checking interval
Indoor : every 20 seconds
Outdoor : every 4 seconds
Transmission distance : maximum 330 feet (100 meters) in open field
Power source (Alkaline batteries recommended)
Atomic clock : 2 x AA, 1.5V batteries
Sensor : 2 x AA, 1.5V batteries
Battery life : about 24 months
Dimensions (L x W x H)
Atomic clock : 12.20“ x 1.18“ x 8.03“ / 310 x 30 x 204mm
Sensor : 5.05” x 1.50” x 0.83” / 128.3 x 38.2 x 21.2 mm
