2040 Antenna assembly
For access, remove these FRUs in order:
v “1010 Battery pack” on page 80
v “1100 Wireless WAN slot cover and PCI Express Mini Card for wireless WAN”
on page 96
v “1110 Palm rest assembly with cables” on page 98
v “1120 PCI Express Mini Card for wireless LAN” on page 101
v “1160 Keyboard” on page 107
v “1170 Keyboard bezel” on page 110
v “1180 LCD unit” on page 112
v “2010 LCD front bezel” on page 136
v “2020 Speaker assembly” on page 137
v “2030 Integrated camera” on page 138
Table 38. Removal steps of antenna assembly
Release the antenna cables from the cable guides of the LCD rear cover assembly
and from the hinges.
For ThinkPad SL510, L510, L512:
1
1
11
1
1
When installing: Route the cables as shown in this figure. When you route the
cables, make sure that they are not subjected to any tension. Tension could cause
the cables to be damaged by the cable guides, or a wire to be broken.
Removing and replacing a FRU 139
