SPECIFICATIONS
IS4220 SPECIFICATIONS
OPERATIONAL
Light Source: 650 nm VLD
Depth of Field: 12.7 mm to 203 mm (.5" to 8") for .33 (13 mil) bar code
Width of Scan Field: 28.6 mm (1.125”) @ face; 102 mm (4”) @ 76.2 mm (3”)
Scan Speed: 52 scans lines per second
Scan Pattern: Single scan line
Min Bar Width: 0.173 mm (6.8 mil)
Decode Capability:
Autodiscriminates all standard bar codes; for other
symbologies call a Metrologic representative
System Interfaces:
RS232, Light Pen Emulation, PC Keyboard Wedge, Stand
Alone Keyboard, USB (low speed)
Print Contrast: 35% minimum reflectance difference
Number of
Characters Read:
up to 80 data characters (Maximum number will vary based
on symbology and density)
Roll, Pitch, Yaw: 42°, 68°, 52°
Beeper Operation: 3 tones or no beep
Indicators (LED): red = laser on, ready to scan green = good read, decoding
MECHANICAL
Length x Width x Height: 70 mm x 49 mm x 24 mm (2.75" x 1.94” x 0.94”)
Weight: 105 grams (3.7 oz.)
Cable Termination: Application Dependent
ELECTRICAL
Input Voltage: 5VDC ± 0.25V
Power: 0.75 W
Operating Current: 135 mA
DC Transformers: Class 2; 5VDC @ 300 mA
Laser Class 2:
EN 60825-1:1993+A1:1997+A2:2001
EN 60825-1:1994+A11:1996+A2:2001
EMC: FCC, ICES-003 & EN 55022 Class A
ENVIRONMENTAL
Operating Temperature: -20°C to 50°C (-4°F to 122°F)
Storage temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5% to 95% relative humidity, non-condensing
Light Levels: Up to 4842 Lux (450 footcandles)
Shock: Designed to withstand 1.5 m (5’) drops
Contaminants: Sealed to resist airborne particulate contaminants
Ventilation: None required
Specifications subject to change without notice.
