Monitor
Specifications
MultiSync
®
LCD175VXM+ Notes
LCD Module Diagonal :
Viewable Image Size :
Native Resolution
(Pixel Count) :
17.0 inch
17.0 inch
1280 x 1024
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.264 mm
dot pitch; 270cd/m
2
white luminence;
700:1 contrast ratio, typical
Input Signal Video :
Sync :
ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Separate sync. TTL Level (Positive/Negative)
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors 16,7M Depending on display card used.
Maximum Viewing
Angles
Left/Right :
Up/Down :
80°/80° (CR>10)
75°/85° (CR>10)
Synchronization
Range
Horizontal :
Vertical :
31.5 kHz to 81.1 kHz
56.0 Hz to 76.0 Hz
Automatically
Automatically
Resolutions
Supported
720 x 400*
1
:VGA text
640 x 480*
1
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
@ 60 Hz to 75 Hz
1152 x 864*
1
@ 70 Hz to 75 Hz
1152 x 870*
1
@ 75 Hz
1280 x 960*
1
@ 60 Hz to 75 Hz
1280 x 1024 at 60 Hz to 75 Hz..................
Some systems may not support all
modes listed.
NEC DISPLAY SOLUTIONS
cites recommended resolution
at 60 Hz for optimal display
performance.
Active Display Area Horizontal :
Vertical :
338.0 mm/13.3 inches
270.3 mm/10.6 inches
Power Supply 100 – 240 V~ 50/60 Hz
Speaker Practical Audio Output 1+1 watts
Current Rating 0.6 - 0.4 A/100-240V
Dimensions 368.0 mm (W) x 379.0 mm (H) x 205.0 mm (D)
14.5 inches (W) x 14.9 inches (H) x 8.1 inches (D
Weight 4.8 kg
10.6 lbs
Environmental
Considerations
Operating Temperature :
Humidity :
Altitude :
Storage Temperature :
Humidity :
Altitude :
5°C to 35°C/41°F to 95°F
10% to 80%
0 to 10,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear
different. This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel
technologies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution
must be done.
NOTE: Technical specifications are subject to change without notice.
