OSM
™
(On-Screen-Manager) Controls
The OSM controls on the front of the monitor function as follows:
Control Main Menu Sub-Menu
EXIT Exits the OSM controls. Exits to the OSM controls
main menu.
CONTROL / Moves the highlighted Moves the highlighted area
area up/down to select up/down to select one of the
one of the controls. controls.
CONTROL –/+ Has no function. Moves the bar in the + or –
direction to increase or
decrease the adjustment.
PROCEED Proceeds to the selected Activates Auto Adjust feature.
menu choice (indicated In Display Mode, opens
by the highlighted area). additional window.
RESET: The currently Resets all the controls within Resets the highlighted control.
highlighted control to the highlighted menu.
the factory setting.
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the reset function.
Brightness and Contrast
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Auto Adjust Contrast: Corrects the image displayed for non-standard video inputs.
Auto Adjust
MultiSync
®
LCD400
™
monitor: Allows automatic adjustment of the Position
and Image Adjust controls.
MultiSync
®
LCD2000
™
monitor: Allows automatic adjustment of the Position
and Image Adjust Coarse control.
Position
Controls horizontal and vertical image position within the display
area of the LCD.
Auto Adjust Position: Automatically sets the horizontal and vertical image
position within the display area of the LCD.
Image Adjust
Coarse: Adjusts the horizontal size by increasing or decreasing the Coarse setting.
Fine: Improves focus, clarity and image stability by increasing or
decreasing the Fine setting.
NOTE: The Image Adjust Fine control must be used to complete the setup of
your MultiSync LCD
2000
monitor.
Auto Adjust Coarse/Fine: (MultiSync LCD
400
monitor only) Automatically
adjusts the Coarse or Fine settings.
Auto Adjust Coarse: (MultiSync LCD
2000
monitor only) Automatically
adjusts the Coarse setting.
Controls
