Controls
AccuColor
™
Control System
Color presets select the desired color setting. If a setting is adjusted, the name of
the setting will change to Custom
.
Color Gain (Red, Green, Blue): Increases or decreases Red, Green or Blue
color depending upon which is selected. The change in color will appear on
screen and the direction (increase or decrease) will be shown by the color
bars.
OSM
™
Location
You can choose where you would like the OSM control image to appear on
your screen. Selecting OSM Location allows you to manually adjust the
position of the OSM control menu left, right, up or down.
OSM Turn Off Time
The OSM control menu will stay on as long as it is in use. In the OSM Turn
Off Time submenu, you can select how long the monitor waits after the last
touch of a button to shut off the OSM control menu. The preset choices are
10, 20, 30, 60 and 120 seconds.
OSM Lock Out
This control completely locks out access to all OSM control functions. When
attempting to activate OSM controls while in the Lock Out mode, a screen
will appear indicating the OSM controls are locked out. To activate the
OSM Lock Out function, press PROCEED, then and hold down simulta-
neously. To de-activate the OSM Lock Out, press PROCEED, then
and hold
down simultaneously.
Display Mode
Display Mode provides information about the current resolution display and
technical data including the preset timing being used and the horizontal and
vertical frequencies.
NOTE: Mode Change should only be used if a resolution is not recognized
by the monitor. The user can change to the appropriate resolution
by entering the Display Mode sub-menu and selecting the
corresponding option.
Language Select
OSM control menus are available in six languages.
Factory Preset
Selecting Factory Preset allows you to reset all OSM control settings back to
the factory settings. The RESET button will need to be held down for several
seconds to take effect. Individual settings can be reset by highlighting the
control to be reset and pressing the RESET button.
