OSM ON/OFF
This control allows you to enable the OSM control.
The OSM control is available when ON is selected. When the OSM does not
appear, the visual and raster controls are available with the remote control.
PC-CONTROL
This control allows you to activate the PC-control function.
For more information see the following pages.
1
2
34
5
11
12
13
1415
6
7
8
9
10
PC/External Control Function
PC/External Control Port Pin Assignments
Pin No.
1
6
2
7
11
12
3
8
9
4
5
10
13
14
15
Mini D-SUB 15pin (Input/Throughout)
Signal Name
No Connection
Receive Data
No Connection
Transimit Data
No Connection
Clear to Send
No Connection
Request to Send
Ground
Input Select
Input Select
Power ON/OFF
No Connection
Degauss ON/OFF
Signal Ground
EXT-CTL
EXT-CTL
EXT-CTL
EXT-CTL
External Control
Pin No.
VIDEO1
VIDEO2
RGB1
RGB2
POWER OFF
POWER ON
DEGAUSS OFF
DEGAUSS ON
4
OPEN
GND
OPEN
GND
-
-
-
-
5
OPEN
OPEN
GND
GND
-
-
-
-
10
-
-
-
-
OPEN
GND
-
-
14
-
-
-
-
-
-
OPEN
GND
LANGUAGE
OSM menus are available in six languages: English, German, French,
Spanish, Italian, and Swedish.
VIDEO MODE
This control allows you to select the NTSC, PAL, or SECAM video standard.
Normally select AUTO.
NOTE: ❊EXT-CTL ON : EXT-CTL active
OFF: EXT-CTL inactive
PC CTL can work regardless of whether EXT-CTL is set or not.
Pin No.8 is connected to pin No. 12.
