NEC VT470 Projector User Manual



8
1. Introduction
Part Names of the Remote Control
NOTE: If you are using a Macintosh computer, you can click
either the MOUSE R-CLICK or MOUSE L-CLICK button to
activate the mouse. (VT676/VT670/VT470 only)
1. Infrared Transmitter
Direct the remote control toward the remote sensor
on the projector cabinet.
2. POWER ON Button
When the main power is on, you can use this button
to turn your projector on.
NOTE: To turn on the projector, press and hold the POWER
ON button for a minimum of two seconds.
3. POWER OFF Button
You can use this button to turn your projector off.
NOTE: To turn off the projector, press the POWER OFF
button twice.
4. MAGNIFY (+)(–) Button
Use this button to adjust the image size up to 400%.
The image is magnified about the center of the screen.
See page 30.
VOLUME
S-VIDEO
VIDEO
L-CLICK
ENTER
EXIT
MENU
UP
MAGNIFY PAGE
OFF
POWER
ON
PIC-MUTE
DOWN
MOUSE
R-CLICK
AUTO ADJ.COMPUTER
ASPECT HELP
FREEZEPICTURE
1
2
1
3
4
7
6
9
2
8
10
11
13
14
12
20
21
19
16
15
18
5
17
5. PIC-MUTE Button
This button turns off the image and sound for a short
period of time. Press again to restore the image and
sound.
6. PAGE UP/DOWN Button
(Not available on VT575 and VT47)
Use these buttons to operate your computer with the
supplied remote mouse receiver. See page 31. You
can use these buttons to scroll the viewing area of the
window or to move to the previous or next slide in
PowerPoint on your computer.
7. MENU Button
Displays the menu for various settings and adjust-
ments.
8. SELECT ̆̄̇̈ (Mouse) Button
̆̄ : Use these buttons to select the menu of the
item you wish to adjust.
̇̈ : Use these buttons to change the level of a se-
lected menu item. A press of the ̈ button ex-
ecutes the selection.
When an image is magnified, the SELECT ̆̄̇̈
button moves the image. See page 30.
9. ENTER Button
Use this button to enter your menu selection. It works
the same way as the ENTER button on the cabinet.
See page 6.
10. EXIT Button
It works the same way as the EXIT button on the cabi-
net. See page 6.
11. MOUSE L-CLICK Button
(Not available on VT575 and VT47)
This button works as the mouse left button when the
supplied remote mouse receiver is connected with your
computer. See page 31.
12. MOUSE R-CLICK Button
(Not available on VT575 and VT47)
This button works as the mouse right button when the
supplied remote mouse receiver is connected with your
computer. See page 31.
13. VIDEO Button
Press this button to select a video source from a VCR,
DVD player, laser disc player or document camera.
14. S-VIDEO Button
Press this button to select an S-Video source from a
VCR.
