17
2. Installation and Connections
Connecting an External Monitor
MONITOR OUT
AUDIO
AC IN
AUDIO OUT
MONITOR OUT
PC CONTROL
AUDIO
S-VIDEO IN
COMPUTER 2 IN
VIDEO IN
COMPUTER 1 IN
AUDIO
L/MONO
R
AUDIO
L/MONO
R
MONITOR OUT
You can connect a separate, external monitor to your projector to simultaneously view on a monitor the RGB analog
image you're projecting.
To do so:
1. Turn off the power to your projector, monitor and computer.
2.
Use an RGB/VGA cable to connect your monitor to the MONITOR OUT (Mini D-Sub 15 pin) connector on your projector.
3. Connect the supplied power cable. See page 20.
4. Turn on the projector, monitor and the computer.
NOTE: Daisy chain connection is not possible.
RGB/VGA signal cable (supplied)
RGB/VGA signal cable (not supplied)
