Quick Reference
CM 1830 Cash Register 5/621/3300 (13)
Olympia 09.2001 Page 1 All rights reserved.
This quick reference only provides basic information.
For more detailed information, please refer to the Operating Instructions manual.
Insert paper roll
Connect the cash register to the power supply. The message
appears in the display and an acoustic signal is
issued. Press the key to stop the acoustic alarm. Open the printer lid. Set the key-operated switch to R. Insert
the paper rolls (37 mm width) for the receipt and journal in the paper holders. Do not use recycled paper. This causes
the printer to wear more quickly. Prepare the paper rolls for insertion. Unroll the first layer and cut the end of paper
straight. This prevents a paper jam occurring. The end of the paper rolls must be at the bottom. The journal paper must
be fed over the end of paper sensor as illustrated below. Insert the end of the paper roll, cut straight, into the printer
mechanism and press
(receipt) or (journal) accordingly, until approx. 10 cm has been fed through.
Depending on the roll used, feed the paper past the tear-off edge on the printer lid or onto the paper reel. Close the
printer lid. Press the key.
Paper reel
The paper reel is required when the journal paper should be rolled onto it.
1. Open the printer lid.
2. Remove the paper reel.
3. Thread the end of the journal roll in the slit of the paper reel.
4. Insert the paper reel in the reel guides provided for it.
5. In order to remove the journal paper after it has been rolled up on the reel, remove
the paper reel and pull the journal paper roll off.
6. Reinsert the paper reel.
7. Close the printer lid.
Change ribbon cassette
Note: Only use original ribbons.
1. Open the printer lid
2. Pull the ribbon cassette up and out using the grip provided.
3. Insert the new ribbon cassette in the printer so that the ribbon is positioned between
the print head and paper. Latch the ribbon cassette in place by pressing lightly.
4. Tighten the ribbon by turning the wheel in the direction of the arrow.
5. Close the printer lid.
Key-operated switch
The key should be set to position R (Registration) for normal operation.
Off Registrations
(normal operation)
X-reports (without
memory deletion)
Z-reports (with
memory deletion)
Programming Training
Note: Loss of data and blocking of the cash register are possible in operating modes Z and P. Only use these
modes when you are familiar with programming and operating the cash register.
