9 Optiquest Q191wb
ENGLISH
Other Information
Specifications
1
Macintosh computers older than G3 require a ViewSonic
®
Macintosh adapter. To order an adapter, contact
ViewSonic.
LCD Type
Color Filter
19” (full 19" viewable diagonal area),
TFT (Thin Film Transistor), Active Matrix WXGA+ LCD,
0.285 mm pixel pitch
RGB vertical stripe
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync
f
h
:30-65 kHz, f
v
:55-75 Hz
Compatibility PC
Macintosh
1
Up to 1440 x 900 Non-interlaced
Power Macintosh up to 1440 x 900
Resolution Recommended
and supported
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 72, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50-60 Hz (auto switch)
Display area Full Scan 410.4 mm (H) x 256.5 mm (V)
16.16" (H) x 10.09" (V)
Operating
conditions
Temperature
Humidity
Altitude
+41° F to +104° F (+5° C to +40° C)
20% to 80% (non-condensing)
To 13,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4° F to +131° F (-20° C to +55° C)
20% to 85% (non-condensing)
To 40,000 feet
Dimensions Physical 464.09 mm (W) x 382.55 mm (H) x 169 mm (D)
18.27" (W) x 15.1" (H) x 6.65" (D)
Weight Physical 9.26 lb (4.2 kg)
Regulations BSMI, C-Tick, CE, ISO 13406-2, Gost-R/Hygienic, Ukraine, UL/cUL,
FCC-B, ICES-B, NOM, TUV-S/IRAM/UL-AR S Mark, E
NERGY STAR
®
Power saving
modes
On
Off
35 W (Typical) (blue LED)
<1W
Preset Timing Mode (pre-adjusted to VESA
®
1440 x 900 @ 60 Hz)
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in
permanent damage to the LCD display.
