GENERAL OPERATION OF THE ALTIMETER
In Altimeter Mode, by detecting changes in air pressure,
the EB833 determines a given altitude level.
Subsequently, the unit can be set to show changes in
altitude and maximum / minimum elevations. It can store
altitude-related data and display elevation trends over a
12-hour period of time. The unit can also display the net
total of accumulative ascents.
A small
icon indicates that the unit is in Altimeter
Mode and that the displays are altitude related.
To view display sequences in Altimeter Mode:
1. Press [ALT] to move between various Altimeter
Mode displays.
Normal Altitude Display
The first display in Altimeter Mode.
NOTE If the unit is being used for the first time, it will
automatically enter the Normal Altimeter Display.
Display shows:
Follow these steps to install or replace batteries:
1. Open battery cover located at the back of the unit by
removing screws.
2. Insert 2 (two) new CR-2032 Lithium batteries.
3. Replace the battery cover.
A battery-low indicator [ BATT ] will show on the display
when the batteries require changing.
It is recommended that when the user is stationary at one
elevation, that the unit is placed in Barometer Mode. The
Altimeter Mode may shorten battery life. Stored altitude
related data is not affected by having the unit in Barometer
Mode for extended periods of time.
NOTE Disposed of improperly, batteries can be
harmful. Protect the environment by taking
exhausted batteries to authorized disposal
stations.
CURRENT
ALTITUDE
CURRENT
TIME
NORMAL ALTITUDE DISPLAY
ALTITUDE
ICON
ALTITUDE
TREND
GRAPH
CURRENT
TEMPERATURE
