TABLE OF CONTENTS
Section
Page
1.0 Warranty Information .............................................................2
1.1 Radio and TV Interference
1.2 CE Notice
1.3 Service
2.0 General Information...............................................................4
2.1 Product Features
2.2 General Product Description
3.0 Configuration .........................................................................5
3.1 Configuration Switch S1
4.0 Installation .............................................................................9
4.1 Connection to Fiber Interface
4.2 Connection to the Serial Port
4.3 Power Connection
5.0 Operation.............................................................................14
5.1 Power- Up
5.2 LED Status Monitors
5.3 Test Modes
Appendix A - Specifications
Appendix B - Factory Replacement Parts and Accessories
Appendix C - Interface Pin Assignments
1
1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 1184 and 1185
components to be free from defects, and will—at our option—repair or
replace the product should it fail within one year from the first date of
shipment.
This warranty is limited to defects in workmanship or materials,
and does not cover customer damage, abuse or unauthorized
modification. If this product fails or does not perform as warranted,
your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages
incurred by the use of this product. These damages include, but are
not limited to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronics specifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 1184 and 1185 generate and use radio frequency
energy, and if not installed and used properly—that is, in strict
accordance with the manufacturer's instructions—may cause
interference to radio and television reception. The Model 1184 and
1185 have been tested and found to comply with the limits for a Class A
computing device in accordance with the specifications in Subpart J of
Part 15 of FCC rules, which are designed to provide reasonable
protection from such interference in a commercial installation.
However, there is no guarantee that interference will not occur in a
particular installation. If the Model 1184 or 1185 do cause interference
to radio or television reception, which can be determined by
disconnecting the unit, the user is encouraged to try to correct the
interference by one or more of the following measures: moving the
computing equipment away from the receiver, re-orienting the receiving
antenna and/or plugging the receiving equipment into a different AC
outlet (such that the computing equipment and receiver are on different
branches).
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Technical
Support.
2
