1.3 SERVICE
All warranty and non-warranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Service at (301) 975-1007, at our web site at
http://www.patton.com, or at support@patton.com.
NOTE: Packages received without an RMA number will not be
accepted.
Patton Electronics' technical staff is also available to answer any
questions that might arise concerning the installation or use of your
Model 1184 or 1185. Technical Service hours: 8AM to 5PM EST,
Monday through Friday.
2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If any questions or problems
arise during installation or use of this product, please do not hesitate to
contact Patton Electronics Technical Support at (301) 975-1007;
2.1 FEATURES
• Model 1184: Synchronous data rates: 4.8 - 128 kbps
Asynchronous data rates: 0-19.2 kbps
• Model 1185: Synchronous data rates: 2.4 - 256 kbps
Asynchronous data rates: 0 - 38.4 kbps
• Full duplex operation over a single
multi-mode fiber optic cable
• Point-to-point distances up to 3 miles
• Internal, external or receive recovered clocking options
• Field Replaceable DTE-DCE QuickConnect™ interface modules:
V.24/RS-232, V.35, RS-422/530, X.21 and G.703
• V.54 compliant local and Remote Digital Loopback tests
• 8 Front Panel LED Status Indicators
• Available with ST or SMA Fiber Connectors
• Made in the U.S.A.
2.2 DESCRIPTION
The Patton Model 1184 and 1185 are designed for high speed
RS-232 communication over a single multi-mode fiber. Operating up
to 128 kbps synchronous and 19.2 kbps asynchronous data rates,
Model 1184 is perfect for campus applications where data integrity is a
must. And Model 1185 is even faster at a bursty 256 kbps
synchronous or 38.4 kbps async.! Synchronous clocking options
include internal, external, or receive recovered clock.
Both Models 1184 and 1185 feature replaceable Patton’s DCE-
DTE QuickConnect™ interface modules. Available interfaces include
V.24/RS-232, V.35, RS-422/530, X.21, Ethernet Bridge and G.703.
Fiber connections are made using a ST or SMA type interface.
The Model 1184 and 1185 also incorporate V.54 compliant local
and remote loopback test modes that are activated by a convenient
front panel switch. LED status indicators monitor interface data and
control signals as well as test mode status. Available with options for
AC or DC power supply, the Models 1184 and 1185 conveniently fit in a
wide range of applications and power supply environments.
