MULTISTATION PC INSTALLATION AND OPERATIONS MANUAL
7
Installing the PCI card
Ground yourself to a grounded metal
object before installing the PCI card
1. Remove the computer cover and
locate an un-used PCI slot on the
motherboard
2. Install the MultiStation PC PCI card
in the PCI slot by firmly applying
uniform pressure on the top of the
card until it seats properly in the
PCI slot
3. Secure the PCI card with the
proper size screw
4. Replace the computer cover
Figure 2. PCI card
Note: The two dipswitches located on the MultiStation PC’s PCI card
should initially be in the “OFF” position (Default shipped position). If
the dipswitches are not in the “OFF” position, set them both to the
“OFF” position before applying any power.
DO NOT install additional cards and remote user modules at this time.
Complete the installation for one and have one user fully operational
before installing additional cards.
