Samsung E1920 Computer Monitor User Manual



Using the product 3-36
SIZE & POSITION
Menu Description
H-Position
Moves the position of the display area on the screen horizontally.
This function is only available in Analog mode.
When a 720P, 1080i or 1080P signal is input in AV mode ,select <Screen Fit >to adjust
horizontal position in 0-6 levels.
V-Position
Moves the position of the display area on the screen vertically.
This function is only available in Analog mode.
When a 720P, 1080i or 1080P signal is input in AV mode ,select <Screen Fit >to adjust
vertical position in 0-6 levels.
Image Size
Supplied for the wide models only such as 16:9 or 16:10.
PC signals
<Auto> - The picture is displayed at the aspect ratio of the input signal.
<Wide> - The picture is displayed in full screen regardless of the aspect ratio of the input signal.
A signal not in the standard mode table is not supported.
If the resolution is set to the optimal resolution, the aspect ratio does not change whether the
<Image Size> is set to <Auto> or <Wide>.
AV signals
<4 : 3> - Displays pictures at the 4 : 3 aspect ratio.
<16 : 9> - Displays pictures at the 16 : 9 aspect ratio.
<Screen Fit> - If a 720P, 1080i or 1080P signal is input in HDMI/DVI input mode, the picture is
displayed as is without truncation.
This can only be set when the external input is connected through HDMI/DVI and <PC/AV
Mode> is set to <AV>.
<4 : 3> - Displays pictures at the 4 : 3 aspect ratio.
<wide> - Displays pictures at the 16:10 aspect ratio.
<Screen Fit> - If a 720P, 1080i or 1080P signal is input in HDMI/DVI input mode, the picture is
displayed as is without truncation.
It can only be selected if an external input is connected to the HDMI/ DVI terminal and the
<PC/AV Mode> is set to <AV>.
When the panel is of 16:10,the screen size options include <4:3>,<wide>,<Screen fit>.
Menu H-Position You can adjust the horizontal position of the OSD.
Menu V-Position You can adjust the vertical position of the OSD.
