2 Press POWER on the projection TV.
The TIMER/STANDBY indicator
lights in green.
For KP-43T75C/53SV75C/61SV75C
only
Press POWER on the projector TV.
2
Press SET UP inside the drop-down
panel.
The AUTO SET UP screen appears.
VOLUME +
VOLUME
+
CHANNEL
+
No :
Auto Programación?
¿Continuar
S í :
[CH]
[CH+]
POWER
Auto Set Up :
Españ ol :
English :
Franç ais :
[VOL]
[CH]
[CH+]
[VOL+]
Oprima
[
SET UP
]
para
salir.
Primero conecte el
cable/antena.
POWER
MAIN POWER
Basic Set Up (continued)
1
Turn on the projector TV.
For KP-43T75A/53SV75A only
1 Depress MAIN POWER on the right
side of the porjection TV.
The projection TV enters standby mode
and the TIMER/STANDBY indicator
lights in red.
TV/VIDEO
FLASH FOCUS
MENUSET UP
TV/VIDEO
FLASH FOCUS
VOLUME
POWER
TIMER/STAND BY
+
CHANNEL
+
MAIN POWER
KP-43T75A/
53SV75A
only
Inside the drop-down panel
Right side
Front panel
Auto Set Up :
Españ ol :
English :
Portuguê s :
[VOL]
[CH]
[CH+]
[VOL+]
Oprima
[
SET UP
]
para
salir.
Primero conecte el
cable/antena.
SET UP
KP-43T75A/53SV75A
only
KP-43T75C/53SV75C/
61SV75C only
3
Press CHANNEL +, CHANNEL – or
VOLUME + to select the desired on-
screen language: English, Español or
Português (KP-43T75A/53SV75A), or
English, Español or Français (KP-
43T75C/53SV75C/61SV75C).
The screen will change to reflect your
choice.
4
Press VOLUME – to continue.
13
5
Press CHANNEL + to preset channels
automatically.
“Auto Programación” appears and the
projection TV starts scanning and
presetting channels automatically. While
scanning, the received channel will be
displayed on the sub screen. When all the
receivable channels are stored, the lowest
numbered channel is displayed.
To perform AUTO SET UP again
Press SET UP inside the drop-down panel on
the projection TV and perform steps 3-5 on
pages 12 and 13.
Press SET UP again to exit.
CHANNEL
+
Adjusting the Convergence
Automatically (FLASH FOCUS)
The projection tube image appears on the
screen in three layers (red, green and blue). If
they do not converge, the color is poor and
the picture blurs.
Before you use your projection TV, be sure to
adjust the convergence.
The FLASH FOCUS feature allows you to
adjust the convergence automatically.
Tips
z
It is recommended to perform FLASH FOCUS about
30 minutes after the projection TV is first turned on.
You can also perform FLASH FOCUS using the
Ajustes menu on page 29.
Press FLASH FOCUS.
The cross pattern appears and FLASH
FOCUS begins to work. The adjustment is
completed when the cross pattern becomes
white.
Note:
FLASH FOCUS is canceled if you
perform any other function while FLASH
FOCUS is working.
Auto Programación
FLASH FOCUS
