– 105 –
KP-43T75C/53SV75C/61SV75C
RM-Y906RM-Y906RM-Y906
C1716 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1717 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1718 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1719 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1720 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1721 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1722 1-128-551-11 ELECT 22µF 20% 25V
C1723 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1724 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1725 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1726 1-128-551-11 ELECT 22µF 20% 25V
C1727 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1728 1-128-551-11 ELECT 22µF 20% 25V
C1729 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1730 1-126-959-11 ELECT 0.47µF 20% 50V
C1731 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1732 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C1733 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1735 1-163-127-00 CERAMIC CHIP 270pF 5% 50V
C1901 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1902 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1903 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1904 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1905 1-128-551-11 ELECT 22µF 20% 25V
C1906 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C1907 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1908 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1909 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C1910 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1911 1-128-551-11 ELECT 22µF 20% 25V
C1912 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1913 1-164-346-11 CERAMIC CHIP 1µF 16V
C1914 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C1915 1-164-346-11 CERAMIC CHIP 1µF 16V
C1916 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1917 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1918 1-164-005-11 CERAMIC CHIP 0.47µF 16V
C1919 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1920 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1921 1-126-963-11 ELECT 4.7µF 20% 50V
C1922 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1923 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C1924 1-126-960-11 ELECT 1µF 20% 50V
C1925 1-164-005-11 CERAMIC CHIP 0.47µF 16V
C1926 1-128-551-11 ELECT 22µF 20% 25V
C1927 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1928 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1929 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1930 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C1931 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1932 1-128-551-11 ELECT 22µF 20% 25V
C1933 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1934 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1935 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1936 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1937 1-128-551-11 ELECT 22µF 20% 25V
C1938 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1939 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1940 1-128-551-11 ELECT 22µF 20% 25V
C1941 1-128-551-11 ELECT 22µF 20% 25V
C1942 1-128-551-11 ELECT 22µF 20% 25V
C1943 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1944 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1945 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1946 1-163-239-11 CERAMIC CHIP 33pF 5% 50V
C1947 1-163-239-11 CERAMIC CHIP 33pF 5% 50V
C1948 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1949 1-126-960-11 ELECT 1µF 20% 50V
C1950 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1951 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1952 1-128-551-11 ELECT 22µF 20% 25V
C1953 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1954 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1955 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C1958 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1959 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1960 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1961 1-128-551-11 ELECT 22µF 20% 25V
C1962 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1963 1-126-960-11 ELECT 1µF 20% 50V
C1964 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1965 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1966 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1967 1-128-551-11 ELECT 22µF 20% 25V
C1969 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1970 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1971 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1972 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
<CONNECTOR>
CN001 * 1-564-507-11 PLUG, CONNECTOR 4P
CN002 * 1-564-513-11 PLUG, CONNECTOR 10P
CN003 1-573-979-21 CONNECTOR, BOARD TO BOARD 11P
CN151 1-695-915-11 TAB (CONTACT)
CN202 * 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
CN203 * 1-564-509-11 PLUG, CONNECTOR 6P
CN204 * 1-564-512-11 PLUG, CONNECTOR 9P
CN205 1-695-915-11 TAB (CONTACT)
CN402 * 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
CN403 * 1-564-507-11 PLUG, CONNECTOR 4P
CN681 * 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
CN801 * 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
CN802 * 1-564-511-11 PLUG, CONNECTOR 8P
CN1702 1-764-334-11 PLUG, CONNECTOR 11P
<DIODE>
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
D003 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-069-55 DIODE UDZS-TE17-5.6B
D005 8-719-988-61 DIODE 1SS355TE-17
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
