2-24 SPARCserver 2000E PowerSupply Installation Manual—April 1995
2
Note – The following screen display is an example only. The actual message
displayed on the screen will vary with the software running on the system.
Note – When a system is started for the first time, or if the master board is
replaced, OBP will prompt you to select a system board to be the new system
master. The system master is normally in slot 0.
If there is no terminal on this system, you must check the system status by
inspecting LEDs on the front panel and if present) on the power supply
adapter board. See Figure 2-22 and Figure 2-23.
Table 2-1 summarizes LED status conditions during and after POST.
Figure 2-22 Front Panel Status LEDs
<<<< SPARCsystem 2000XX POST VX.X >>>>
...(various test messages)...
SPARCsystem 2000 Series (2 X XXXXXX), No Keyboard
ROM Rev. -.-, --- MB Memory installed, Serial #---.
Ethernet address -:-:--:-:--:--, Host ID: ------.
DC power (green)
Fault (yellow)
System running (green)
