1-4
LS 2100 Product Reference Guide
3. Insert a new cable in the receptacle. Press the cable firmly into the receptacle until
you hear a click.
Connecting to a Host
Plug the connector at the end of the LS 2100 cable into the appropriate port on the Symbol
interface controller or portable terminal. Refer to the controller user documentation for full
details.
Figure 1-3. Connecting to a Host
LS 2100
Interface
Controller
Host
Computer
Portable
Data
Terminal
LS 2100
