23
AUTO CONFIG : Allows the entry of optimum geometrical adjustments based on the input mode
INFORMATION : Displays the input mode information on the screen.
MISCELLANEOUS
You may enter the factory default settings, Menu position and duration on the screen, resolution
settings etc. by selecting the MISCELLANEOUS option.
FACTORY RESET : Loads the factory default settings
OSD TIMEOUT : The on-screen timeout may be adjusted to a value between
5 - 60 seconds.
OSD POSITION : Used for adjusting the OSD Horizontal and Vertical position
NATIVE MODE : Displays the input cursor in its actual resolution
TV SELECTION : To change from Monitor mode to TV mode
GAMMA : Correction of linear RGB data to compensate for non-linear response of TFT display.
MOIRE :
Correction of distortions giving an image of the picture lines superimposed over one
another.
SAVE : Stores the settings entered.
NOTE: The user can store the geometrical adjustments (H-Position, V-Position) entered for 6
different input graphic modes. When the Autoconfig is performed, the settings provided for that
mode are stored, therefore, activating the Autoconfig function each time the mode is changed, is not
necessary. When the user stores the settings for a 7th mode, the first mode stored will be erased
Warning Messages
1. No SYNC: The VGA input code (resolution) is missing. The "NO SYNC" message appears on
the display. The message stays on the screen for 30 seconds and if no other VGA input signal that
is supported by the system is not provided within that period, the system will go to "POWER
SAVING" mode in order to protect the LCD panel. In this mode, the display will turn off, but the
sound from the selected tuner channel will be audible
2. Input Not Supported: The input code (resolution) is not a supported graphics mode. The message
"INPUT NOT SUPPORTED" appears on the display. The message stays on the screen until a
supported graphic input code is received.
Input Graphic Modes Supported (progressive non-interlaced)
Important Warning:
1. When the system changes from TV mode to VGA mode for the first time, the sound from
the speakers is muted, but available through the ear-phones
2. When a particular VGA mode is displayed for the first time, selecting the
"Autoconfiguration" option may be necessary. The position adjustment as well as the H-
Position and V-Position fine adjustments must be entered and the values "saved (stored)"
3. When the signal is cut off, depending on the VGA power-saving standard, the message
"NO SIGNAL" is displayed on the screen for 30 seconds. At the end of this period, the
system turns off, providing an energy saving of 30 watts.
640 x 400 x 56 Hz
640 x 480 x 60 Hz
640 x 480 x 69 Hz
640 x 480 x 72 Hz
640 x 480 x 75 Hz
640 x 350 x 70 Hz
640 x 480 x 66 Hz (MAC)
640 x 480 x 85 Hz
720 x 400 x 70 Hz
720 x 400 x 85 Hz
800 x 600 x 56 Hz
800 x 600 x 60 Hz
800 x 600 x 72 Hz
800 x 600 x 75 Hz
800 x 600 x 85 Hz
832 x 624 x 75 Hz
1024 x 768 x 60 Hz
1024 x 768 x 70 Hz
1024 x 768 x 75 Hz
1024 x 768 x 85 Hz
