Multimedia Projector MP8745 © 3M 1999
TECHNICAL
A-8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
D-sub 15pin (Female)
610
1511
Computer
CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI
Projector
SEL0
RTS
GND
RDP
TDP
15
D-sub 9pin
69
1
2
3
4
5
6
7
8
9
Serial mouse
A.7 Connection to the Control Signal Terminal (continued)
RS-232 Control Cable (not included with basic packout)
This cable is used to directly control the projector without using the Remote Control or Operator's Panel.
Serial Mouse cable
(male)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
D-sub 15pin (Female)
610
1511
Computer
CD
RD
TD
DTR
GND
DSR
RTS
CTS
RI
Projector
SEL0
RTS
GND
RD
TD
15
D-sub 9pin (male)
69
1
2
3
4
5
6
7
8
9
RS-232 Cable
