Table 8-4 Parallel Poll Enable Register

Bit Position Bit Weight Enables

15 -8 Not used

7 128 Not used

6 64 MSS - Master Summary Status

5 32 ESB - Event Status

4 16 MAV - Message Available

3 8 LCL - Local

2 4 Not used

1 2 Not used

0 1 MSB - Module Summary

*RST (Reset)

The *RST command is not implemented on the Agilent 1670G-series logic

analyzer. The Agilent 1670G-series logic analyzer will accept this command,

but the command has no effect on the logic analyzer.

The *RST command is generally used to place the logic analyzer in a

predefined state. Because the Agilent 1670G-series allows you to store

predefined configuration files for individual modules, or for the entire system,

resetting the logic analyzer can be accomplished by simply loading the

appropriate configuration file. For more information, refer to chapter 12,

"MMEMory Subsystem."

Common Commands

*RST (Reset)

8–14
