RUNTil (Run Until)
Command :MACHine{1|2}:TWAVeform:RUNTil <run_until_spec>
The RUNTil command defines stop criteria based on the time between the X
and O markers when the trace mode is in repetitive. When OFF is selected,
the analyzer will run until either STOP is selected from the front panel or the
STOP command is sent. Run until options are:
•
Less Than (LT) a specified time value
•
Greater Than (GT) a specified time value
•
In Range (INRange) between two time values
•
Out of Range (OUTRange) between two time values
End points for INRange and OUTRange should be at least 2 ns apart since
this is the minimum time at which data is sampled.
This command affects the timing analyzer only, and has no relation to the
RUNTil commands in the SLISt and COMPare subsystems.
<run_until_
spec>
{OFF | LT,<value> | GT,<value> | INRange,<value>,
<value> | OUTRange,<value>,<value>}
<value> real number
Example
OUTPUT XXX;":MACHINE1:TWAVEFORM:RUNTIL GT, 800.0E−6"
OUTPUT XXX;":MACHINE1:TWAVEFORM:RUNTIL INRANGE, 4.5, 5.5"
Query :MACHine{1|2}:TWAVeform:RUNTil?
The RUNTil query returns the current stop criteria.
Returned Format
[:MACHine{1|2}:TWAVeform:RUNTil] <run_until_spec><NL>
Example OUTPUT XXX;":MACHINE1:TWAVEFORM:RUNTIL?"
