<lower_bits> format (integer from 0 to 65535) for a pod (pods are assigned in decreasing
order)
<assignment> format (integer from 0 to 65535) for a pod (pods are assigned in decreasing
order)
Example OUTPUT XXX;":MACHINE2:TFORMAT:LABEL ’STAT’, POSITIVE,
0,127,40312"
OUTPUT XXX;":MACHINE2:TFORMAT:LABEL ’SIG 1’,
#B11,#B0000000011111111,
#B0000000000000000 "
Query :MACHine{1|2}:TFORmat:LABel? <name>
The LABel query returns the current specification for the selected (by name)
label. If the label does not exist, nothing is returned. Numbers are always
returned in decimal format.
Returned Format
[:MACHine{1|2}:TFORmat:LABel] <name>,<polarity>[,
<assignment>]...<NL>
Example OUTPUT XXX;":MACHINE2:TFORMAT:LABEL? ’DATA’"
REMove
Command :MACHine{1|2}:TFORmat:REMove {<name>|ALL}
The REMove command deletes all labels or any one label specified by name
for a given machine.
<name> string of up to 6 alphanumeric characters
Example OUTPUT XXX;":MACHINE1:TFORMAT:REMOVE ’A’"
OUTPUT XXX;":MACHINE1:TFORMAT:REMOVE ALL"
TFORmat Subsystem
REMove
21–7
