22-EN
1
Press SOURCE/ .
The SOURCE selection screen is displayed.
2
Touch [Disc]*.
The display shows the Disc screen.
Insert a disc with the label side facing up. The unit starts to
play the disc.
When an optical Alpine DVD player is connected, insert a
disc into the DVD/CD player, and the player starts playing.
* When you want to play a DivX file from a USB device, touch [USB].
• The operation screen changes to the visual screen in the DVD mode
for 5 seconds after an operation has been performed. Touch the
display panel to display the operation screen again.
• The display mode can be changed by touching [WIDE].
For operation, see “Switching Display Modes” on page 30.
To eject the disc
Press .
• The reverse side of a double-sided DVD will not be played
automatically.
Remove the disc, turn it over, and reinsert it.
• If the disc does not eject, press and hold for at least 3 seconds.
• Do not insert discs containing maps for the navigation system. Doing
so could result in damage.
• Be sure that the remote input lead is connected to the remote output
lead of this unit when a DVD player is connected. If not correctly
connected, touching operation cannot be performed.
• Refer also to “DVD Setup” (pages 31 to 32).
• If the disc is left in the unit after pressing , the disc is
automatically pulled back into the unit and stopped. In this case,
start playback by touching [
/ ] or eject again and remove the
disc within 15 seconds.
• While “Index reading” is displayed by DivX®, the fast-forwarding/
fast-reversing and repeat functions, etc. cannot be used.
On DVDs, menu screens may appear automatically. If this happens,
perform the operation described below to start playback.
Direct Menu Operations
1 Touch the DVD menu directly.
Menu Operations
1 Touch screen to display the operation keys.
2 Touch [Key].
The menu operation mode will be displayed.
3 Select a desired menu item by touching [ ], [ ], [ ] or [ ].
4 Touch [Enter] to confirm the selected item.
Numeric Keypad Input Operations
1 Touch screen to display the operation keys.
2 Touch [Key].
The menu operation mode appears.
3 Touch [Key] again.
The numeric keypad input mode screen appears.
4 Touch a desired number.
5 Touch [Enter] on the numeric keypad mode screen to confirm
your selection.
If a menu screen appears
• Some operations cannot be performed depending on the disc.
Touch [] to return to the previous display.
(Operation may not be possible, depending on the disc.)
The numeric keypad input screen closes when
the area is touched while being displayed.
Touch [] to close the
numeric keypad input screen.
