128800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0546−14 Assemblies include all parts shown in frames. 11/27/2007
14
121 498260 Kit−Carburetor
Overhaul
125 498170 Carburetor
(Primer System)
(Used After Code Date
96060200).
−−−−−−− Note −−−−−
498254 Carburetor
(Primer System)
(Used Before Code
Date 96060300).
790821 Carburetor
(Primer System)
Used on Type No(s).
1771, 1781, 1946,
2042.
125A 498965 Carburetor
(Choke System)
(Used After Code Date
96060200).
−−−−−−− Note −−−−−
497501 Carburetor
(Choke System)
(Used Before Code
Date 96060300).
499059 Carburetor
(Choke System)
Used on Type No(s).
0807, 0839, 0888,
1192, 1907, 1910,
1921, 1939, 1961,
1977, 2007, 2011,
2040, 2046, 2047,
2318, 2332, 2333,
2392, 2393, 2394,
2395, 2626, 2644,
2681, 3112, 3132,
3134, 3135, 3170,
4305, 4605, 4905,
4906.
790978 Carburetor
(Choke System)
Used on Type No(s).
1724, 1728, 1729,
1772, 1773.
792253 Carburetor
(Choke System)
Used on Type No(s).
1906, 2325, 2643.
125B 790845 Carburetor
(Autochoke System)
127 D694468 Plug−Welch
(3/8” Diameter)
127A D691739 Plug−Welch
(5/16” Diameter)
130 691203 Valve−Throttle
−−−−−−− Note −−−−−
696564 Valve−Throttle
(Primer System)
(Used After Code Date
01040800).
130A 691181 Valve−Throttle
133 398187 Float−Carburetor
134 D398188 Kit−Needle/Seat
137Dz693981 Gasket−Float Bowl
144 493824 Pulley/Spring
Assembly
146 690979 Key−Timing
159 691753 Bracket−Air Cleaner
Primer
163KD
z272653 Gasket−Air Cleaner
187 791766 Line−Fuel
(Cut to Required
Length)
−−−−−−− Note −−−−−
791745 Line−Fuel
(23” Long)(Cut to
Required Length)
(Used After Code Date
05063000).
Used on Type No(s).
2105.
296004 Line−Fuel
(23” Long)(Cut to
Required Length)
(Used Before Code
Date 05070100).
Used on Type No(s).
2105.
187A 791873 Line−Fuel
(Molded)
187B 791891 Line−Fuel
(Includes Filter)
(Used After Code Date
05063000).
−−−−−−− Note −−−−−
692042 Line−Fuel
(Includes Filter)
(Used Before Code
Date 05070100).
187C 791875 Line−Fuel
(Molded)
188 690877 Screw
(Control Bracket)
190 690940 Screw
(Fuel Tank)
202 691829 Link−Mechanical
Governor
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
