128800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0546−17 Assemblies include all parts shown in frames. 11/27/2007
17
305 691108 Screw
(Blower Housing)
306 690450 Shield−Cylinder
306A 790836 Shield−Cylinder
307 690345 Screw
(Cylinder Shield)
309 695550 Motor−Starter
(Used Before Code
Date 07052900).
309A 795092 Motor−Starter
(Used After Code Date
07052800).
310 692327 Bolt
(Starter Motor)
332 690662 Nut
(Flywheel)
333 802574 Armature−Magneto
−−−−−−− Note −−−−−
790817 Armature−
Magneto
Used on Type No(s).
1771, 1772, 1773,
1946, 2042.
333A 792640 Armature−Magneto
(Screw On Spark Plug
Boot)
−−−−−−− Note −−−−−
793353 Armature−
Magneto
(Snap In Spark Plug
Boot)
792631 Armature−
Magneto
(Screw On Spark Plug
Boot)
Used on Type No(s).
1771, 1772, 1773,
2042.
793354 Armature−
Magneto
(Snap In Spark Plug
Boot)
Used on Type No(s).
1771, 1772, 1773,
1778, 1779, 1781,
1782, 2042, 2048,
2049.
334 691061 Screw
(Magneto Armature)
337 802592S Plug−Spark
(Resistor)
−−−−−−− Note −−−−−
697451 Plug−Spark
(EMS)
346 690661 Screw
(Spark Arrestor)
347 691396 Switch−Rocker
356 692390 Wire−Stop
356A 690650 Wire−Stop
356B 693010 Wire−Stop
356D 496381 Wire−Stop
357 695867 Key−Drive Pulley
358 497316 Gasket Set−Engine
363 19069 Flywheel Puller
365 691688 Screw
(Carburetor)
374 691074 Washer
(Camshaft)
383 89838S Wrench−Spark Plug
404 690272 Washer
(Governor Crank)
425A 690670 Screw
(Air Cleaner Cover)
443A 692523 Screw
(Air Cleaner Primer
Base)
445A 491588S Filter−Air Cleaner
Cartridge
455 791960 Cup−Flywheel
455A 224250 Cup−Flywheel
456 692299 Plate−Pawl Friction
456A 224321 Plate−Pawl Friction
459 281505S Pawl−Rachet
459A 492833 Pawl−Ratchet
474 691991 Alternator
497 690664 Screw
(Stopswitch Bracket)
500 691086 Washer
(Key Switch)
505 691251 Nut
(Governor Control
Lever)
510 795093 Drive−Starter
513 692358 Drive−Clutch
523 499621 Dipstick
524 K692296 Seal−Dipstick Tube
525 495265 Tube−Dipstick
529 691923 Grommet
544 690786 Armature−Starter
545 492919 Washer Set
(Starter Motor)
562 691119 Bolt
(Governor Control
Lever)
564 690664 Screw
(Control Cover)
564A 691142 Screw
(Control Cover)
564B 698589 Screw
(Control Cover)
578 398153 Wire Assembly
584 697734 Cover−Breather
Passage
585 K691879 Gasket−Breather
Passage
592 690800 Nut
(Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp−Hose
601A 691038 Clamp−Hose
604 691757 Cover−Control
604A 691344 Cover−Control
604B 790703 Cover−Control
604D 793770 Cover−Control
608 497680 Starter−Rewind
−−−−−−− Note −−−−−
791363 Starter−
Rewind
Used on Type No(s).
1945.
608A 497598 Starter−Rewind
613 691340 Screw
(Muffler)
−−−−−−− Note −−−−−
790833 Screw
(Muffler)
Used on Type No(s).
1777, 1778, 1779,
1782, 1916, 1918,
1943, 1945, 1987,
2048, 2049.
613A 691653 Screw
(Muffler)
613B 691114 Screw
(Muffler)
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
