128800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0546−18 Assemblies include all parts shown in frames. 11/27/2007
18
615 690340 Retainer−Governor
Shaft
616 698801 Crank−Governor
617KDz270344 Seal−O Ring
(Intake Manifold)
621 692310 Switch−Stop
627 692872 Bracket−Stop Switch
−−−−−−− Note −−−−−
792565 Bracket−Stop
Switch
Used on Type No(s).
1907, 1977, 2040,
2046, 2047, 4305.
633Dz691321 Seal−Choke/Throttle
Shaft
(Throttle Shaft)
633ADz693867 Seal−Choke/Throttle
Shaft
(Choke)
635 66538S Boot−Spark Plug
635A 792597 Boot−Spark Plug
(Screw On Style)
−−−−−−− Note −−−−−
793351 Boot−Spark
Plug
(Snap On Style)
651 691660 Screw
(Starter Gear Cover)
664 691087 Nut
(Key Switch)
668 K493823 Spacer
(Includes 2)
670 692294 Spacer−Fuel Tank
676 396548 Deflector−Muffler
(Single Louver)
676B 397931 Deflector−Muffler
(Direct Out)
(3/4” Diameter)
676C 493871 Deflector−Muffler
(Side Out)
(Extended)
(17/32” Deep)
676D 497682 Deflector−Muffler
(Direct Out)
(1 3/16” Diameter)
676E 393760 Deflector−Muffler
(Side Out)
(7/16” Deep)
677 690661 Screw
(Muffler Deflector)
678 224278 Spacer−Rewind
684 690345 Screw
(Breather Passage
Cover)
689 691855 Spring−Friction
689A 262625 Spring−Friction
692 690572 Spring−Detent
697 691127 Screw
(Drive Cap)
715 691147 Screw
(Stop Shaft)
718 690959 Pin−Locating
721 690449 Stop−Shaft
741 794388 Gear−Timing
(Use Without Woodruff
Key)
(Used After Code Date
07093000).
−−−−−−− Note −−−−−
790345 Gear−Timing
(Use Without Woodruff
Key)
(Used Before Code
Date 07100100).
691830 Gear−Timing
(Uses Woodruff Key)
742 93941 Retainer−E Ring
743 691772 Gear−Drive
(Counterclockwise)
−−−−−−− Note −−−−−
690516 Gear−Drive
(Clockwise)
Used on Type No(s).
1955.
745 691648 Screw
(Brake)
783 691918 Gear−Pinion
(Starter Drive)
(19 Teeth)
783A 691269 Gear−Pinion
(12 Teeth)
784 795095 Cover−Starter Gear
785 692352 Gasket−Starter Cover
789 695551 Harness−Wiring
(Used After Code Date
00040600).
−−−−−−− Note −−−−−
690790 Harness−
Wiring
(Used Before Code
Date 00040700).
789A 691372 Harness−Wiring
(Used Before Code
Date 00040700).
789B 696547 Harness−Wiring
801 690782 Cap−Drive
802 695267 Cap−End
(Used After Code Date
00040600).
−−−−−−− Note −−−−−
695975 Cap−End
(Used Before Code
Date 00040700).
803 695266 Housing−Starter
(Used After Code Date
00040600).
−−−−−−− Note −−−−−
695975 Housing−
Starter
(Used Before Code
Date 00040700).
832 499034 Guard−Muffler
(Super Lo Tone Tuned)
832A 691424 Guard−Muffler
(Square Lo Tone)
832B 497683 Guard−Muffler
(Super Lo Tone
Catalyst)
836 690664 Screw
(Muffler Guard)
836B 690661 Screw
(Muffler Guard)
842 K691031 Seal−O Ring
(Dipstick Tube)
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
