• Source IPv6 Prefix Length—Enter the prefix length of the source IPv6
address.
• Source Port—Select this option to include a source port in the match
condition for the rule. The source port is identified in the datagram header. If
selected, choose the port name or enter the port number.
• Destination IPv6 Address—Select this field to require a packet's
destination IPv6 address to match the address listed here. Enter an IPv6
address in the appropriate field to apply this criteria.
• Destination IPv6 Prefix Length—Enter the prefix length of the destination
IPv6 address.
• Destination Port—Select this option to include a destination port in the
match condition for the rule. The destination port is identified in the datagram
header. If selected, choose the port name or enter the port number.
• IPv6 Flow Label—A 20-bit number that is unique to an IPv6 packet. It is used
by end stations to signify QoS handling in routers (range 0 to 1048575).
• IP DSCP—Matches packets based on their IP DSCP value. If selected,
choose one of these options as the match criteria:
- Select From List—DSCP Assured Forwarding (AS), Class of Service
(CS), or Expedited Forwarding (EF) values.
- Match to Value—A custom DSCP value, from 0 to 63.
For a MAC ACL, configure these parameters:
• EtherType—Select to compare the match criteria against the value in the
header of an Ethernet frame.
Select an EtherType keyword or enter an EtherType value to specify the
match criteria.
- Select from List—Select one of these protocol types: appletalk, arp,
ipv4, ipv6, ipx, netbios, pppoe.
- Match to Value—Enter a custom protocol identifier to which packets are
matched. The value is a four-digit hexadecimal number in the range of
0600 to FFFF.
• Class of Service—Select this field and enter an 802.1p user priority to
compare against an Ethernet frame.
The valid range is from 0 to 7. This field is located in the first/only 802.1Q
VLAN tag.
