Radio Statistics
You can use the Radio Statistics page to show packet-level and byte-level
statistics for the wireless radio interface. To view the Radio Statistics page, select
Status and Statistics > Radio Statistics in the navigation pane.
• Packets Received—Total packets received by the WAP device.
• Packets Transmitted—Total packets transmitted by the WAP device.
• Bytes Received—Total bytes received by the WAP device.
• Bytes Transmitted—Total bytes transmitted by the WAP device.
• Packets Receive Dropped—Number of packets received by the WAP
device that were dropped.
• Packets Transmit Dropped—Number of packets transmitted by the WAP
device that were dropped.
• Bytes Receive Dropped—Number of bytes received by the WAP device
that were dropped.
• Bytes Transmit Dropped—Number of bytes transmitted by the WAP
device that were dropped.
• Fragments Received—Number of fragmented frames received by the
WAP device.
• Fragments Transmitted—Number of fragmented frames sent by the WAP
device.
• Multicast Frames Received—Count of MSDU frames received with the
multicast bit set in the destination MAC address.
• Multicast Frames Transmitted—Count of successfully transmitted MSDU
frames where the multicast bit was set in the destination MAC address.
• Duplicate Frame Count—Number of times a frame was received and the
Sequence Control field indicates it was a duplicate.
• Failed Transmit Count—Number of times an MSDU was not transmitted
successfully due to transmit attempts exceeding either the short retry limit
or the long retry limit.
