Item Indicator, button, or
connector
Icon Description
To reset iDRAC (if not disabled in F2 iDRAC setup)
press and hold the button for more than 15
seconds.
2 System identification
connector
Connects the optional system status indicator
assembly through the optional cable management
arm.
3 iDRAC8 Enterprise port Dedicated management port.
4 Half-height PCIe
expansion card slot (3)
Allows you to connect up to three half-height PCI
Express expansion cards.
5 Serial connector Allows you to connect a serial device to the
system.
6 Video connector Allows you to connect a VGA display to the system.
7 USB connector (2) Allows you to connect USB devices to the system.
The ports are USB 3.0-compliant.
8 Full-height PCIe
expansion card slot (4)
Allows you to connect up to four full-height PCI
Express expansion cards.
9 Ethernet connector (4) Four integrated 10/100/1000 Mbps NIC
connectors
or
Four integrated connectors that include:
• Two 10/100/1000 Mbps NIC connectors
• Two 100 Mbps/1 Gbps/10 Gbps SFP+/10 GbE T
connectors
10 Power supply unit (PSU1)
AC 495 W, 750 W, or 1100 W
or
DC 750 W or 1100 W
11 Power supply unit
(PSU2)
19
