FENIX IMVICO
TK14 OPERATION MANUAL
14/65
2.3- RS-232 SERIAL INTERFACE
2.3.1- RS-232 Serial interface specifications
•
Data transmission type: Serial
•
Synchronization: Asynchronous
•
Flow control: DTR/DSR control
•
Signal levels (RS232): MARK = -3 to -15 V Logic ‘1’/OFF
SPACE = +3 to +15 V Logic ‘0’/ON
•
Speed: 4800, 9600, 19200, 38400 bps (bps: bits per second)
•
Data length: 8 bits
•
Parity: none, even, odd
•
Stop bits: Fixed to 1
•
Connector (user side): JST
PHDR-18VS
(housing)
SPHD-001T-P0.5
(contact) or an equivalent model.
NOTE:
(1) Speed and parity depend on the settings (refer to section 3.6.2).
2.3.2- Change between online and offline mode
The printer is in offline mode:
1) When powering up or resetting the printer, until the printer is ready to receive data.
2) When the platen is opened.
3) After pressing the Paper feed button (FEED) while the paper advances.
4) When ‘out of paper’ causes the printer to stop printing.
5) When the power supply has a temporal abnormal voltage change.
6) When an error has occurred.
