HandyTone-486 User Manual Grandstream Networks, Inc.
18
DM
IP:
Port Forwarding:
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
WAN port
0
LAN IP LAN port
0
Protocol
" UDP Only"
Update
Cancel
Reboot
All Rights Reserved Grandstream Networks, Inc. 2005
End User
Password
This contains the password to access the Web Configuration
Menu. This field is case sensitive with max. 25 characters
IP Address
There are 2 modes where the HandyTone ATA can operate:
- If DHCP mode is enabled, then all the field values for the Static
IP mode are not used (even though they are still saved in the
Flash memory.) The HandyTone ATA will acquire its IP address
from the first DHCP server it discovers from the LAN it is
connected.
To use PPPoE feature set the PPPoE account settings here if
connect the box to DSL modem. The HandyTone will attempt to
establish a PPPoE session if any of the PPPoE fields is set. In this
mode, the WAN side web access is disabled and TFTP upgrade
for firmware is not feasible and HTTP upgrade is only available
solution.
- If Static IP mode is selected, then the IP address, Subnet Mask,
Default Router IP address, DNS Server 1 (primary), DNS Server
2 (secondary) fields will need to be configured. These fields are
reset to zero by default.
